3M Compatible 6P6C Voice Keystone Jack RJ11/RJ12 Telephone Module

جزئیات محصول

محل منبع: گوانگدونگ، هویژو

نام تجاری: LINK-PP

گواهی: UL,RoHS,Reach,ISO

شماره مدل: جک کیستون صوتی 3M 6P6C

شرایط پرداخت و حمل و نقل

مقدار حداقل تعداد سفارش: 10 عدد

قیمت: $0.25

جزئیات بسته بندی: نوار و حلقه

زمان تحویل: امروز کشتی سهام

شرایط پرداخت: L/C، D/A، D/P، T/T، وسترن یونیون

قابلیت ارائه: 5 کیلوگرم در ماه

بهترین قیمت را دریافت کنید
برجسته کردن:

3M compatible keystone jack

,

3M 6P6C module

,

Corning Volition telephone jack

رابط رابط:
6-موقعیت، 6-تماس (6P6C)
سازگاری سیستم:
3M و Corning Volition
درجه عملکرد:
دسته 3 (Cat3)
روش خاتمه:
استاندارد 110 IDC
دوام تماس بگیرید:
پین های 50 میکرونی با روکش طلا
مصالح مسکن:
ترموپلاستیک (نقد UL 94V-0)
رابط رابط:
6-موقعیت، 6-تماس (6P6C)
سازگاری سیستم:
3M و Corning Volition
درجه عملکرد:
دسته 3 (Cat3)
روش خاتمه:
استاندارد 110 IDC
دوام تماس بگیرید:
پین های 50 میکرونی با روکش طلا
مصالح مسکن:
ترموپلاستیک (نقد UL 94V-0)
3M Compatible 6P6C Voice Keystone Jack RJ11/RJ12 Telephone Module


6P6C Keystone Jack Overview

Stop struggling with standard keystone jacks that won't fit your existing wall plates. This Voice Grade 6P6C Keystone Jack is specifically molded with a proprietary footprint designed to seamlessly snap into 3M and Corning Volition series faceplates and patch panels.

Engineered for reliable analog voice and telecom applications, this Cat3 module features a standard 6-Position, 6-Contact (6P6C) interface. It is fully backwards compatible with RJ11 (6P4C/6P2C) connectors, making it the perfect drop-in replacement for repairing or expanding legacy telephone systems, fax lines, and modems in commercial environments.

Key Features:

  • True 3M/Corning Compatibility: Custom-designed housing guarantees a secure, flush fit with 3M Volition and Corning telecommunication faceplates. Solves the common frustration of incompatible standard keystone dimensions.
  • Versatile 6P6C Interface: Supports up to 3 active telephone lines. Works flawlessly with standard RJ12 plugs, and safely accepts standard RJ11 telephone cords without damaging the outer pins.
  • Crystal Clear Voice Transmission: Features 50-micron gold-plated contacts to prevent corrosion and oxidation, ensuring static-free, reliable voice signal quality over years of use.
  • Standard 110 Punch-Down Termination: Equipped with industry-standard 110 IDC (Insulation Displacement Contact) terminals for fast, secure wire seating using a standard punch-down tool. Includes a clear plastic retention cap to keep wires locked in place.




Specifications of 6P6C Voice Keystone Jack

Feature Specification
Product Type Voice / Telephone Keystone Module
System Compatibility 3M / Corning Volition Series Only
Connector Interface 6P6C (Compatible with RJ12 & RJ11)
Performance Category Category 3 (Cat3) - Voice Grade
Termination Style 110 IDC Punch-Down block
Supported Wire Gauge 22 - 26 AWG Solid Copper Wire
Contact Plating Heavy-duty Gold Plating for durability




3M Type 6P6C keystone Jack Details


3M Compatible 6P6C Voice Keystone Jack RJ11/RJ12 Telephone Module 0



3M Compatible 6P6C Voice Keystone Jack RJ11/RJ12 Telephone Module 1




The "3M Footprint" Explained: Why Standard Keystone Jacks Fail


If you are managing an IT infrastructure in a building outfitted with 3M or Corning Volition wall plates, you have likely discovered a frustrating reality: standard universal keystone jacks do not fit. The 3M Volition series utilizes a proprietary mounting footprint featuring slightly different latching dimensions. This specially engineered 6P6C module solves that problem. It is custom-molded to match the exact dimensions of the 3M/Corning locking mechanism, ensuring a flush, secure snap-in fit that won't push back into the wall when a cable is inserted.




6P6C Interface: Understanding RJ11 vs. RJ12 Compatibility


This jack features a true 6P6C (6-Position, 6-Contact) interface, commonly referred to as an RJ12 connection. This means all six slots contain active gold-plated pins, allowing it to support up to three distinct analog telephone lines simultaneously.

Is it compatible with standard phone cords?** Yes. The jack is fully backwards compatible with standard RJ11 (6P4C or 6P2C) plugs used for single or dual-line desktop phones. The housing is designed so that inserting a smaller RJ11 plug will not bend or damage the outermost pins.



Ideal Applications & Use Cases


While data networks have largely moved to Cat6/Cat6A RJ45 modules, Cat3 voice-grade modules remain essential for specific telecom applications. This module is the perfect drop-in replacement for:


  • Legacy analog telephone systems (PBX).
  • Dedicated fax machine lines.
  • Analog modems or point-of-sale (POS) terminal connections.
  • Elevator or emergency alarm phone lines that require hardwired analog connections.
  • Retrofitting and maintaining older commercial buildings, schools, and hospitals originally wired with 3M infrastructure.
